Whirlpool top loader Washing Machine motor controller pcb

Price 2555.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Piece

Whirlpool top loader Washing Machine motor controller pcb Specification

Type
Washer

Material
PLASTIC

Power Source
Electric

Voltage
220 Volt (v)

Loading Type
Top Loading

Tub Material
Plastic

Color
GREEN

Weight (kg)
250 Gram (g)

Warranty
TESTING WARRANTY

Whirlpool top loader Washing Machine motor controller pcb Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Week

About Whirlpool top loader Washing Machine motor controller pcb

The motor controller PCB in a Whirlpool top-load washing machine is a dedicated electronic board that controls the washing machine motors speed, direction, and performance.

Key Functions & Description:

Motor Speed Control:
Regulates motor RPM for different operations like wash, rinse, and spin cycles.
Direction Control (Forward/Reverse):
Alternates motor rotation to ensure proper cloth movement and effective cleaning.
Inverter / Drive Circuit (in advanced models):
Uses components like IGBT/MOSFET to convert and control power for smooth, energy-efficient motor operation.
Load Sensing & Protection:
Detects overload, imbalance, or motor jam and protects the system by stopping or adjusting operation.
Voltage Regulation:
Converts and stabilizes incoming power supply for safe motor driving.
Communication with Main PCB:
Receives commands from the main control board and sends feedback (speed, error status).
