Whirlpool Double Door refrigerator Pcb

Name: Whirlpool Double Door refrigerator Pcb
Brand: Betelleave
Price: 2955.0 INR
Availability: InStock

Price 2955.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Whirlpool Double Door refrigerator Pcb Specification

Application
Double Door Refrigerator

Power Supply
Single Phase

Operating Temperature Range
0C to 50C (Approx.)

Dimensions
Standard as per Whirlpool refrigerator design

Product Type
Refrigerator PCB (Printed Circuit Board)

Mounting Type
Plug-in/Standard Mounting

PCB Weight
Approx. 120g

Input Voltage Range
100V - 260V AC (Approx.)

Replacement Type
Direct Replacement PCB for Whirlpool Double Door Series

Board Type
Main Control PCB

Compatible Brand
Whirlpool

Usage
Controls refrigerator functions such as cooling and defrost

Whirlpool Double Door refrigerator Pcb Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Week

Delivery Time
1 Week

Packaging Details
CUSTOM PACKAGING

Main Export Market(s)
Asia

Main Domestic Market
All India

Certifications
ISO CERTIFICATIONS

About Whirlpool Double Door refrigerator Pcb

Whirlpool double door refrigerator PCB board is the main electronic control unit (brain) of the appliance, responsible for managing and coordinating all cooling and operational functions. It continuously receives signals from temperature and defrost sensors and controls key components such as the compressor, fan motors, and defrost system, ensuring efficient and stable cooling performance.

This PCB processes sensor data to maintain accurate temperature control in both fridge and freezer compartments, while optimizing energy efficiency and system performance. It also ensures proper synchronization between different components, enabling smooth operation and reliable cooling cycles.

Built with durable electronic components and advanced circuitry, it provides stable operation, long service life, and protection for the compressor, making it an essential replacement part for faulty or non-working refrigerators.

Key Features:

Central control unit for complete refrigerator operation
Controls compressor, fan, and defrost heater
Maintains precise temperature in fridge & freezer
Ensures energy-efficient and stable cooling
Processes sensor inputs for automatic operation
Durable, tested, and reliable PCB design

Core Functionality and Reliability

This Main Control PCB is integral for regulating both cooling and defrost functions in your Whirlpool Double Door Refrigerator. Engineered for consistent reliability, it is designed to operate within a broad voltage and temperature range, making it suitable for varying electrical conditions.

Simple Installation Process

The PCB features a plug-in/standard mounting design, ensuring straightforward installation for technicians and service providers. As a direct replacement, it fits seamlessly into compatible Whirlpool refrigerator models without modifications, reducing maintenance time.

Perfect Compatibility and Quality Assurance

Manufactured to Whirlpool's precise standards, this control board guarantees compatibility with all Double Door models. Each unit is subjected to strict quality checks, providing users assurance of long-lasting and efficient refrigerator performance.

FAQ's of Whirlpool Double Door refrigerator Pcb:

Q: How do I install the Whirlpool Double Door Refrigerator Main Control PCB?

A: The Main Control PCB is designed with a standard plug-in or direct mount, making installation straightforward. Simply remove the old PCB, and position the new board in place, ensuring all connectors are securely attached. It is recommended that a qualified technician handle the replacement.

Q: What functions does this control PCB manage in my refrigerator?

A: This PCB serves as the main control unit, managing critical refrigerator operations such as temperature regulation, cooling cycles, and automatic defrosting processes. It ensures the refrigerator runs efficiently and reliably.

Q: When should I consider replacing the main control PCB?

A: Replacement is typically necessary when the refrigerator displays erratic behavior like cooling failures, faulty defrosting, or total inoperability. Diagnosing the existing PCB for faults or malfunctions will help determine when a replacement is required.

Q: Where can I purchase the Whirlpool Double Door Refrigerator PCB?

A: The control board is available through authorized service providers, suppliers, traders, and wholesalers specializing in Whirlpool or appliance spare parts. Ensure compatibility with your refrigerator model before purchasing.

Q: What is the process for ensuring compatibility with my Whirlpool refrigerator?

A: Check your refrigerator model number and match it with the specified compatible models by Whirlpool. This main control PCB is engineered for Double Door Series refrigerators from Whirlpool, guaranteeing a precise fit and full functionality.

Q: How does replacing the PCB benefit refrigerator performance?

A: Installing a new main control PCB restores accurate temperature and defrost management, optimizes energy efficiency, and helps prevent unexpected breakdowns, ensuring your Whirlpool Double Door Refrigerator operates at its best.
