Lg Inverter Double Door Refrigerator Pcb Board

Name: Lg Inverter Double Door Refrigerator Pcb Board
Brand: Betelleave
Price: 3555.0 INR
Availability: InStock

Price 3555.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Lg Inverter Double Door Refrigerator Pcb Board Specification

Mounting Type
Panel Mount

Connector Type
Pin Header

Circuit Protection
Overload and Short Circuit Protection

Application
Control and Regulate Refrigerator Functions

Suitable For
LG Inverter Double Door Refrigerator

Input Supply
220-240V AC, 50/60 Hz

Dimensions
Approx. 15cm x 10cm

Condition
Brand New

PCB Type
Double Layer PCB Board

Working Temperature
-20C to +60C

Lg Inverter Double Door Refrigerator Pcb Board Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Week

Delivery Time
1 Week

Packaging Details
CUSTOM PACKAGING

Main Export Market(s)
Asia

Main Domestic Market
All India

Certifications
ISO CERTIFICATIONS

About Lg Inverter Double Door Refrigerator Pcb Board

The LG Inverter Double Door Refrigerator PCB Board is the central control unit that manages the complete operation of a frost-free, double door refrigerator using advanced inverter technology.

Key Functions

Inverter Compressor Control:
Regulates compressor speed according to cooling demand, ensuring energy efficiency and silent operation.
Dual Compartment Temperature Control:
Maintains separate and accurate temperatures for both freezer and refrigerator sections.
Frost-Free (Auto Defrost) Operation:
Controls heater and defrost cycle to prevent ice buildup in the freezer.
Fan Motor Management:
Operates evaporator and condenser fans for proper air circulation across both compartments.
Sensor Integration:
Processes data from multiple sensors (temperature, defrost, ambient) for precise performance.
User Interface & Display Control:
Connects with digital display panel for temperature settings, modes (Eco, Quick Freeze, etc.).
Power Supply & Protection:
Converts and stabilizes voltage, with built-in protection from overvoltage, overload, and short circuit.

Main Components

Microcontroller (main IC)
Inverter driver circuit
SMPS (Switched Mode Power Supply)
Relays / Triacs
Capacitors & resistors
Sensor connectors
Communication ports (display & modules)

Precision Control and Advanced Protection

This double layer PCB board guarantees precise regulation of key refrigerator operations. Equipped with robust overload and short circuit protection, it delivers stable and secure performance. Designed for LG inverter double door refrigerators, it helps extend appliance life while minimizing potential electrical faults.

Installation and Versatile Compatibility

With its panel mount design and pin header connector, this PCB board is straightforward to install for service professionals and technicians. The universal size and 220-240V input supply make it broadly compatible with various LG inverter double door models, ensuring dependable operation across multiple installations.

FAQ's of Lg Inverter Double Door Refrigerator Pcb Board:

Q: How do I know if this PCB board is compatible with my LG inverter double door refrigerator?

A: This PCB board is suitable for most LG inverter double door refrigerator models that use a double layer PCB and accept a 220-240V AC, 50/60 Hz supply. You may confirm compatibility by checking your refrigerator's service manual or consulting the supplier with your appliance model number.

Q: What is the process for installing the LG Inverter Double Door Refrigerator PCB Board?

A: Installation involves panel mounting the board in the designated slot inside the refrigerator, connecting the pin header connectors, and powering the system with the standard supply voltage. It is strongly recommended to have installation performed by a qualified technician for safety and correct operation.

Q: When should I consider replacing the refrigerator's PCB board?

A: You should consider replacement when the refrigerator exhibits control failures, frequent shutdowns, or doesn't respond to input, and diagnostics indicate PCB malfunction. A new board restores accurate control and efficiency to your appliance.

Q: What protection features are included in this PCB board?

A: This PCB board comes with built-in circuit protection against overload and short circuits. These safeguards enhance durability and minimize damage to both the board and the refrigerator during power fluctuations.

Q: Where can I buy or source this LG Inverter Double Door Refrigerator PCB Board?

A: This product is typically available through authorized service providers, suppliers, traders, and wholesalers specializing in appliance parts and electronics. Ensure you purchase from reputable sources to guarantee authenticity and warranty support.

Q: What are the benefits of using this PCB board in my refrigerator?

A: Installing this advanced PCB board promotes efficient function regulation, consistent control, and operational safety. Its robust design and protection features contribute to prolonged appliance lifespan and reduced maintenance costs.
