SAMSUNG SINGLE DOOR Refrigerator pcb

Name: SAMSUNG SINGLE DOOR Refrigerator pcb
Brand: Betelleave
Price: 3555.0 INR
Availability: InStock

Price 3555.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SAMSUNG SINGLE DOOR Refrigerator pcb Specification

Brand Compatibility
SAMSUNG Single Door Refrigerators

Application
Replacement/repair electronic controller board

Product Type
PCB Board for Refrigerator

Connector Type
Multi-pin connectors for easy replacement

Voltage Rating
110-240V AC (typical refrigerator PCB spec)

Capacitors
Polymer and Electrolytic Capacitors present

Relay Type
Miniature PCB Mount Power Relays

Dimensions
Approx. 15 cm x 12 cm x 5 cm (may vary)

Material
FR-4 Epoxy Glass Laminated Board

Color
Green solder mask with black enclosure

Condition
New and fully tested

Compatibility Note
Only for Samsung brand single door refrigerator models

Coating
Conformal coated and resin sealed for moisture resistance

Mounting Type
Screw mounting with housing lock

SAMSUNG SINGLE DOOR Refrigerator pcb Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
1 Piece Per Week

Delivery Time
1 Week

Packaging Details
CUSTOM PACKAGING

Main Export Market(s)
Asia

Main Domestic Market
All India

Certifications
ISO CERTIFICATIONS

SAMSUNG SINGLE DOOR Refrigerator pcb About

The Samsung Single Door Refrigerator PCB Board is the primary electronic control unit that manages the refrigerator's cooling and operational functions. It controls key components such as the compressor, temperature sensors, defrost system, and internal cooling mechanisms to ensure consistent performance and energy efficiency.

This PCB board continuously monitors the refrigerator's temperature and adjusts operations automatically to maintain optimal cooling conditions while minimizing power consumption. It is designed for reliable performance, stable operation, and protection against voltage fluctuations.

Common signs of a faulty PCB board include no cooling, compressor not starting, temperature fluctuations, display or indicator issues, continuous running, or complete refrigerator malfunction.

Reliable Replacement Solution

This Samsung refrigerator PCB offers a dependable solution for restoring or enhancing your single door refrigerator's electronic control system. Built with high-grade materials and designed for simple installation, it ensures robust operation and longevity, safeguarding your appliance against unforeseen malfunctions.

Engineered for Compatibility and Performance

Precisely engineered for Samsung single door refrigerator models, the PCB is built on a durable FR-4 epoxy board and incorporates both polymer and electrolytic capacitors, providing optimal voltage regulation and smooth operations. The conformal coating and resin seal protect the circuitry, extending the lifespan of your refrigerator's electronics.

FAQ's of SAMSUNG SINGLE DOOR Refrigerator pcb:

Q: How do I identify if this PCB board is compatible with my refrigerator?

A: This PCB board is specifically designed for Samsung single door refrigerator models. Check your refrigerator's model number and compare it with the compatibility list provided by your supplier, installer, or service provider before purchasing.

Q: What is the benefit of using a conformal coated and resin sealed PCB board?

A: Conformal coating and resin sealing provide superior protection for the PCB against moisture, dust, and other environmental elements, significantly enhancing the durability and reliability of your refrigerator's electronics.

Q: When should I consider replacing my refrigerator's PCB board?

A: You should consider replacing the PCB board if your refrigerator shows electronic control issues, such as failure to start, irregular cooling cycles, or unresponsive display. Always confirm the diagnosis with a qualified technician before replacement.

Q: Where can I get this PCB board installed or replaced?

A: Installation and replacement should be carried out by authorized service providers or trained technicians to ensure safety and compatibility with your specific Samsung single door refrigerator model.

Q: What is the process for replacing the PCB board in my refrigerator?

A: First, disconnect the refrigerator from the power supply. Access the control board compartment, unscrew and unclip the old PCB, and detach connectors carefully. Mount the new PCB using screws and connector pins, then close the compartment and power on the appliance. Professional installation is recommended for best results.

Q: How do the included polymer and electrolytic capacitors improve PCB functionality?

A: Polymer and electrolytic capacitors help stabilize voltage and reduce electronic noise, resulting in more consistent performance and longer life for the refrigerator's circuitry.

Q: What are the usage precautions for this replacement PCB board?

A: Always ensure the power is off before handling the PCB. Only install it in compatible Samsung single door refrigerator models and avoid exposing the board to moisture or physical stress during installation for optimal performance and safety.
