Godrej top loader 5 KG Fully Automatic washing machine pcb board

About Godrej top loader 5 KG Fully Automatic washing machine pcb board

The Godrej 5 KG Fully Automatic Top Load Washing Machine PCB Board is the main electronic control unit responsible for managing all washing machine operations. It receives input from the user control panel and sensors, then controls the motor, water inlet valve, drain pump, and spin functions to ensure smooth and efficient washing performance.

Key Functions:

• Controls wash, rinse, and spin cycles automatically.
• Regulates water filling and drainage operations.
• Manages motor rotation and spin speed.
• Monitors water level and lid switch sensors.
• Controls cycle timing and program selection.
• Provides stable and reliable operation for daily laundry use.

Main Components:

• Microcontroller (Main IC)
• Power Supply (SMPS) Section
• Motor Control Circuit
• Relays and Triacs
• Sensor Input Connectors
• Display and Keypad Interface Circuit
